Modifying guest network interface with the Invoke-VMScript cmdlet



With the news that the ‘Set-VMGuestNetworkInterface’ cmdlet is to be deprecated in the next release of PowerCLI (, the question is how do I now modify the guest network interface?

The ability to perform this action can now be moved to the Invoke-VMScript cmdlet, which is a pretty cool way to invoke a script in the guest operating system of the virtual machine when VMware Tools is installed.

As per the description of the cmdlet you will need to satisfy the below:

To run Invoke-VMScript, the user must have read access to the folder containing the virtual machine and a VirtualMachine.Interaction.Console Interaction privilege. The virtual machines must be powered on and have VMware Tools installed. Network connectivity to the ESX system hosting the virtual machine on port 902 must be present to authenticate with the host or the guest OS, one of the HostUser/HostPassword (GuestUser/GuestPassword) pair and HostCredential (GuestCredential) parameters must be provided. The guest account you use to authenticate with the guest operating system must have administrator’s privileges.

To run this cmdlet against vCenter Server/ESX/ESXi versions earlier than 5.0, you need to meet the following requirements:

*You must run the cmdlet on the 32-bit version of Windows PowerShell.
*You must have access to the ESX that hosts the virtual machine over TCP port 902.
*For vCenter Server/ESX/ESXi versions earlier than 4.1, you need VirtualMachine.Interact.ConsoleInteract privilege.  For vCenterServer/ESX/ESXi 4.1 and later, you need VirtualMachine.Interact.GuestControl privilege.

As mentioned VMware Tools is required to be installed and the virtual machine to be powered on, in my use case modifying the guest network interface is a one of a number of script blocks in deployment script to customise a virtual machine and therefore in order to confirm that VMware Tools is running following a virtual machine power on event I run a statement in a script block until the Guest.ToolsStatus is retrieved as ‘toolsOK’ from the Get-View cmdlet, where the MoRef value for the virtual machine is retrieved from an associated array.

    Start-Sleep -Seconds 10
    $GuestToolsStatus = (Get-View $VM.Id -Property Guest).Guest.ToolsStatus
Until ($GuestToolsStatus -eq toolsOk)

Now we want to modify the guest network interface, with the following requirements.

  • Configure IPv4 address
  • Configure subnet mask
  • Configure default gateway
  • Configure DNS servers

So, in order to modify the guest network interface I will be replacing the soon to be deprecated ‘Set-VMGuestNetworkInterface’ cmdlet with the ‘New-NetIPAddress’ and ‘Set-DnsClientServerAddress’ cmdlets in Windows Powershell.

In order to run the script inside the guest operating system and in this example a Microsoft Windows Server 2012 operating, I will create a ScriptText variable containing the syntax of the two cmdlets I wish to invoke.  Please not the ‘;’ separator to invoke multiple lines of commands in the text of the script.

$ScriptText = "New-NetIPAddress –InterfaceAlias Ethernet0 –IPAddress -AddressFamily IPv4 –PrefixLength 24 -DefaultGateway;
Set-DnsClientServerAddress -InterfaceAlias Ethernet0 -ServerAddresses,"

In the above example, we are modifying the network interface ‘Ethernet0’ to use the IPv4 address with a default gateway and the DNS servers and

Now, let’s actually run the command in the guest operating operating system, using the Invoke-VMScript cmdlet, where guest credentials are retrieved from paramaters supplied for my script.

Invoke-VMScript -VM $VM -ScriptText $ScriptText -GuestUser $GuestUser -GuestPassword $GuestPassword

As you can see this is a powerful way to invoke scripts inside the guest operating system. In the default state the script type invoked on a Microsoft Windows operating system is Powershell. However, you may specify the type to be Bat or for a Linux operating system Bash.

The script above, can be downloaded from

4 thoughts on “Modifying guest network interface with the Invoke-VMScript cmdlet

    1. Thats correct, and in this instance this also could be used used instead of the block you mentioned.

      One consideration for using Wait-Tools cmdlet and probably not applicable in this instance is that some of the VM properties may still be empty after the completion of Wait-Tools.


  1. I have seen properties such as the IP address and operating system full name not being available once Wait-Tools has completed, it is only a minor delay until the information is available.
